Klipschspeakers
Klipsch PSM-650-T
Equipment Sales & Professional Installation
MPN: PSM-650-T
- 6.5" full-range surface-mount speaker
- 1" titanium compression driver
- 70V/100V multi-tap transformer
- All-weather ABS enclosure, IPX6 rated
- 100° dispersion
- EN54-24 certified
- 5-year warranty
Specifications
Specifications
| Type | Full-range 6.5" indoor/outdoor surface-mount loudspeaker |
|---|---|
| Woofer | 6.5" woofer |
| Tweeter | 1" titanium compression driver on K-1200M horn |
| Frequency Response | 56Hz–20kHz ±4dB (46Hz –10dB) |
| Sensitivity | 90dB SPL (1m, half space) |
| Nominal Impedance | 8 ohms (4.5 ohms min) |
| Power Handling | 80W continuous (19V); 320W peak |
| 70V Taps | 60W, 30W, 15W, 7.5W |
| 100V Taps | 60W, 30W, 7.5W |
| Dispersion | 100° ±20° (900Hz–20kHz) |
| Crossover | 2kHz |
| Enclosure | All-weather ABS plastic, paintable, vented (Tractrix ports) |
| IP Rating | IPX6 |
| Input Connector | 4-pin Euroblock (Phoenix) |
| Dimensions (H x W x D) | 12.81" x 10.19" x 7.57" (326mm x 259mm x 193mm) |
| Weight | 11.25 lbs (5.11 kg) |
| Certifications | EN54-24 |
